#shader

2 posts2 participants0 posts today
Public
claude

Doing some experiments with #RayTracing #ComputerGraphics using #Bonzomatic #GLSL #shader editor.

I define a 24-cell as the intersection of 24 half-spaces in 4D (with normals all permutations of (±1,±1,0,0)), then slice through constant 4th coordinate to get a 3D object, and simulate it as a glass-like material with reflection and refraction.

Future enhancement ideas:

- handle polarised light properly (currently I ignore polarisation, simply averaging the Fresnel reflection coefficients)

- wavelength-dependent index of refraction and absorption

- anti-aliasing (currently the edges are steppy as there is only 1 sample per pixel in a regular grid)

- improve efficiency (internal ray bounce is O(N^2) where N is the number of surfaces, could probably be O(N) with some extra maths insights)

- do 4D->3D slicing on CPU instead of every ray bounce

- add other 4D shapes

#Polarisation is something I haven't done before, so I'm curious to see how to implement it and how it changes appearance.

computer graphics representation of a 3D slice of a 4D object. in the middle is a convex shape bounded by flat planes, reflecting and refracting a surrounding sphere that has glowing coloured bands with soft edges. the object is as if made of glass. the bands visible behind the shape are mainly purple/pink/red, with some parts of the object showing other colours that are behind the viewpoint. the multiple relections and refractions are a bit confusing, when animated the shape is a bit easier to see
Public
vade

For those interested in 3D rendering techniques and frameworks, I'm very proud to inherit the reigns of Satin from the incredible Reza Ali.

I found out about Satin too late, as Reza had sunset the public repo after i had learned about it. Sadly it didnt get much traction for reasons I simply don't understand. Its incredibly well put together.

But due to some new opportunities, Reza kindly shared his internal updates - Satin Pro - and I want to help give it the community it deserves.

I'm trying to document Satin, and an ecosystem of examples, sample apps, and community at the Fabric project:

fabric-project.github.io

If you've seen my in progress node based VJ app 'v' - its built with Satin under the hood.

The first new addition to Satin is an attempt at a live coding environment, Velvet, allowing you to experiment with Satin rendering interactively.

#3d#rendering#gpu
